Visit us on the web for our complete product line
www.CNAweb.com
800-516-1262
Fax: 800-236-5672
2 2
IDS Socket
Connectors
CNA#
1-24 25+
85-534
34 Pin IDC
.47
.40
85-540
40 Pin IDC
.43
.35
Hoods
1-24
25+
85-409
DB9/DB15HD Gray Plastic - Cable-Clamp Strain Relief
.30
.24
85-411
DB9/DB15HD Metalized - Cable-Clamp Strain Relief
.45
.36
85-415
DB15 Gray Plastic - Cable-Clamp Strain Relief
.30
.24
85-417
DB15 Metalized Plastic - Cable-Clamp Strain Relief
.58
.46
85-425
DB25 Gray Plastic - Cable-Clamp Strain Relief
.33
.26
85-427
DB25 Metalized Plastic - Cable-Clamp Strain Relief
.50
.40
85-450
DB9 Metal - Diecast Metal
1.53
1.22
85-453
DB15 Metal - Diecast Metal
2.20
1.76
85-455
DB25 Metal - Diecast Metal
2.20
1.76
Crimp Type
Tin Plated Housing,
Requires pins
CNA#
1-24 25+
85-010
DB9, Male
.30
.24
85-110
DB9, Female
.30
.24
85-016
DB15, Male
.45
.39
85-118
DB15, Female
.45
.39
85-022
DB15HD, Male (SVGA)
.47
.39
85-122
DB15HD, Female (SVGA)
.47
.39
85-027
DB25, Male
.30
.24
85-127
DB25, Female
.33
.26
D-Sub Wall Plates
Flush Mount,
Stainless-Steel
CNA#
1-24 25+
85-251
DB9/DB15HD Single
2.20 1.90
85-252
DB9/DB15HD Dual
2.20 1.90
85-271
DB25 Single
2.20 1.90
85-272
DB25 Dual
2.20 1.90
Crimp Pins (Package of 100)
Gold Plated
Contacts
CNA#
1-4 5+
85-055
Male
4.50 3.90
85-155
Female
4.50 3.90
85-057
Male HD (SVGA)
4.50 3.90
85-157
Female HD (SVGA)
4.50 3.90
D-Sub Installation Tools
CNA#
1-4 5+
85-212
D-Sub and Butt connectors.
8.90 7.90
85-200
Insertion/Extraction Tool
2.25 1.93
Solder Type
Gold Plated
Contacts
CNA#
1-24 25+
85-009
DB9, Male
.30
.24
85-109
DB9, Female
.30
.24
85-015
DB15, Male
.35
.28
85-115
DB15, Female
.37
.30
85-020
DB15HD, Male (SVGA)
.45
.30
85-120
DB15HD, Female (SVGA)
.45
.30
85-025
DB25, Male
.47
.40
85-125
DB25, Female
.40
.32
Connectors
Flat Ribbon Cable, 100' Roll
AWG 28 Insulated Displacement Cable,
Gray PVC Jacket, Red Polarizing
Stripe 0.050" Center-to-Center
CNA#
1-4 5+
85-040
40-Conductor
41.50 39.50
D-Sub Modular
Adapters
CNA#
1-9 10+
85-207
9 Pin Male RJ11/12 (6x6)
1.35
.99
85-209
9 Pin Male RJ45 (8x8)
1.35
.99
85-217
9 Pin Female RJ11/12 (6x6
)
1.35
.99
85-219
9 Pin Female RJ45 (8x8)
1.35
.99
85-227
15 Pin Male RJ11/12 (6x6)
1.35
.99
85-237
15 Pin Male RJ45 (8x8)
1.35
.99
85-229
15 Pin Female RJ11/12 (6x6)
1.35
.99
85-239
15 Pin Female RJ45 (8x8)
1.35
.99
85-307
25 Pin Male RJ11/12 (6x6
)
1.35
.99
85-309
25 Pin Male RJ45 (8x8
)
1.35
.99
85-317
25 Pin Female RJ11/12 (6x6
)
1.35
.99
85-319
25 Pin Female RJ45 (8x8)
1.35
.99
Assembly Required
